EPS Foam Material For Helmet

Update::2022-08-30 16:41 View:

EPS(Expandable Polystyrene) is a lightweight, rigid, plastic foam insulation material produced from solid particles of polystyrene. Expandsion is achieved by virtue of small amounts of pentane gas dissolved into the polystyrene base material during production.The gas expands under the action of heat, applied as steam, to form perfectly clesed cells of EPS.

How do we classfiy EPS Material?

Regular Grades - High Expansion, Medium Grade, Fast Cycling, Colorful beads
Specification
P301 P302 P303 P401 P501
Beads Size mm 1.00-1.60 0.85-1.25 0.70-0.90 0.50-0.80 0.40-0.60
Vol.Cont % 7.81 7.66 7.39 7.09 6.82
H2O % 0.45 0.57 0.38 0.51 0.37
Avg. size mm 1.25 1.01 0.81 0.63 0.53
Sieving ≥95% 98.0 100.0 100.0 100.0 99.8
Result (g/l) 12.50 13.50 14.33 19.67 24.00
DENSITY RANGE Max(I) (g/l) 11.00 13.11 14.50 18.67 20.20
Min(I) (g/l) 12.50 14.28 17.67 20.00 25.00
Remark ALL THE DATA IS BASED ON LAB TEST FOR FIRST TIME EXPANSION IN CONTINOUS EXPANDER
